Technical Specs:
Dry Weight - Front	271 lbs (123 kg)
Dry Weight - Rear	430 lbs (195 kg)
Dry Weight - Total	701 lbs (318 kg)
GVWR	1130 lbs (512 kg)
GAWR - Front	390 lbs (177 kg)
GAWR - Rear	740 lbs (336 kg)
GAWR - Rear	740 lbs (336 kg)
Fuel - Total	4.4 gal (16.6 L)
Fuel - Main	4.0 gal (15.1 L)
Fuel - Reserve	0.4 (1.5 L)
Oil Capacity	2.875 - 3 qts (2.7 - 2.8 L)
Frame Rake	39 degrees
Tree Rake	3 degrees
Trail	4.35" (110.5 mm)
Front Suspension	41 mm Telescopic
Fork Length	+12.0" (304.8 mm)
Seat Height	24.25" (616 mm)
Ground Clearance	4.0" (101.6 mm)
Wheel Base	82" (2083 mm)
Total Length	108" (2743 mm)
Front Brake	4-Piston Diff Bore
Rear Brake	4-Piston
Front Tire	MH90-21 56V
Rear Tire	300/35-R18 87V
Front Wheel	21" x 2.15" (533.4 mm x 54.6 mm)
Rear Wheel	18" x 10.50" (457.2 mm x 266.7 mm)
Engine	S&S OHV 45 degree V-Twin
Displacement	117 c.i. (1917 cc)
Bore x Stroke	4.125" x 4.375" (104.8 mm x 111.1 mm)
Compression Ratio	9.6:1
Fuel System	Carbureted / CLEFI
Transmission	Baker 6-Speed
Primary Drive	Comp/Balance Drive
Final Drive	1.125" (28.6 mm) Belt
Ignition	Electronic Single Fire
Charging Output	35 Amp
